Series 7 Contemporary Tall Double Dishdrawer™ Dishwasher

SKU: DD24DCTW9N
Your Price $1,699.99
Price with selected options:
Qty:

Where Can I See This Product in Store?

more
This product is not on display in our showrooms.
Estimated Delivery Price
Enter your zip code to get a delivery estimate.

Ask a Question

less
First Name is required
Last Name is required
Email Address is required
Message is required
Preferred Store is required

Dimensions:

23.56" W × 22.56" D × 34.0" H
remove add
Width (side to side) 23.56
Depth (front to back) 22.56
Height (bottom to top) 34.0

Disclaimer

remove add

Description

remove add
Doing the dishes got easier. Load one drawer while the other washes - with the top drawer fitting your large dinner plates easily.
Finish White
  • N/A
  • Flexible racking can be folded down to fit bigger dishes
  • Six wash programs, as well as additional Quick wash, Sanitize and Extra Dry options
Data Sheet Double DishDrawer%E2%84%A2 Dishwasher
Data Sheet Double DishDrawer%E2%84%A2 Dishwasher
View PDF for more information
Quick Reference guide
Quick Reference guide
View PDF for more information
Quick Reference guide
Quick Reference guide
View PDF for more information
Service & Warranty
Service & Warranty
View PDF for more information
Energy Label Double DishDrawer%E2%84%A2 Dishwasher
Energy Label Double DishDrawer%E2%84%A2 Dishwasher
View PDF for more information
User Guide EN & FR
User Guide EN & FR
View PDF for more information
Installation Guide Double DishDrawer%E2%84%A2 Dishwasher EN
Installation Guide Double DishDrawer%E2%84%A2 Dishwasher EN
View PDF for more information
Installation Guide Double DishDrawer%E2%84%A2 Dishwasher EN
Installation Guide Double DishDrawer%E2%84%A2 Dishwasher EN
View PDF for more information
Installation Guide EN
Installation Guide EN
View PDF for more information

Rebates

view available rebates
Series 7 Contemporary Tall Double Dishdrawer™ Dishwasher
Series 7 Contemporary Tall Double Dishdrawer™ Dishwasher
Dishwashers Collection
Your Price $1,699.99

Specifications

Specifications

remove add

Product

Tall Tub Design Yes
Tall Tub Design
  • Yes
Sabbath Mode No
Sabbath Mode
  • No
Wifi Enabled No
Wifi Enabled
  • No
Dishwasher Sound Rating Quiet (40-49dB)
Dishwasher Sound Rating
  • Quiet (40-49dB)
Appliance Color White
Appliance Color
  • White
Install Type Built-In
Install Type
  • Built-In
ADA Compliant No
ADA Compliant
  • No
Energy Star Compliant Yes
Energy Star Compliant
  • Yes

Dimensions

Height (bottom to top) 34.0" H
Height (bottom to top)
  • 34.0" H
Width (side to side) 23.56" W
Width (side to side)
  • 23.56" W
Depth (front to back) 22.56" D
Depth (front to back)
  • 22.56" D

Features & Function

Maximum Spin Speed (RPM) -1.0
Maximum Spin Speed (RPM)
  • -1.0
Control Location Front
Control Location
  • Front
Decibel Sound Rating 42.0
Decibel Sound Rating
  • 42.0

Style Elements

Color Family White / Cream
Color Family
  • White / Cream
Color Name White
Color Name
  • White

Accessories (sold separately)

Handle kit Contemporary round, aluminium Part number 81674
Handle kit Contemporary round, aluminium
  • Part number 81674

Capacity and loading

Accommodates round plates up to 12.25 " (top) 11" (bottom)
Accommodates round plates up to
  • 12.25 " (top) 11" (bottom)
Place settings 14
Place settings
  • 14

Consumption

Energy usage 265kWh/year
Energy usage
  • 265kWh/year
In-use energy carbon emissions estimate Carbon Emissions Info 97.1kgCO2e/year
In-use energy carbon emissions estimate Carbon Emissions Info
  • 97.1kgCO2e/year
Water usage (per wash cycle) 3.44 gal running both tubs
Water usage (per wash cycle)
  • 3.44 gal running both tubs

Features

Internal tub material N/A
Internal tub material
  • N/A
Flexible racking can be folded down to fit bigger dishes, Six wash programs, as well as additional Quick wash, Sanitize and Extra Dry options
  • Flexible racking can be folded down to fit bigger dishes
  • Six wash programs, as well as additional Quick wash, Sanitize and Extra Dry options

Performance

Noise emissions 42dBA
Noise emissions
  • 42dBA
Noise on standard cycle top drawer 42dBA
Noise on standard cycle top drawer
  • 42dBA

Power requirements

Amperage 10A
Amperage
  • 10A
Electric circuit 3 wire
Electric circuit
  • 3 wire
Rated current 15A
Rated current
  • 15A
Supply frequency 60Hz
Supply frequency
  • 60Hz
Supply voltage 100 - 120V
Supply voltage
  • 100 - 120V

Product dimensions

Depth 22 9 / 16 "
Depth
  • 22 9 / 16 "
Height 34 - 36 3 / 8 "
Height
  • 34 - 36 3 / 8 "
Width 23 9 / 16 "
Width
  • 23 9 / 16 "

Warranty

Parts and labor Limited 2 years
Parts and labor
  • Limited 2 years

Wash Program Modifiers

Wash modifiers 3
Wash modifiers
  • 3

Wash Programs

Wash programs 6
Wash programs
  • 6

Water connection

Water pressure 30kPa - 1000 kPa
Water pressure
  • 30kPa - 1000 kPa
Water supply 3 / 8 " to suit Male Compression Fitting
Water supply
  • 3 / 8 " to suit Male Compression Fitting

Item & Dimensions

Manufacturer Fisher and Paykel
Manufacturer
  • Fisher and Paykel
The Dishwashers Series 7 Contemporary Tall Double Dishdrawer™ Dishwasher, made by Fisher and Paykel, is brought to you by Sherman's. Sherman's is a local furniture store, serving the Peoria, Normal, and Peru, IL area. Product availability may vary. Contact us for the most current availability on this product.

Collection Details

The Dishwashers collection is an amazing option if you are looking for Appliances. Our store serves the Peoria, Normal, and Peru, IL area.
Similar search terms: Dishwasher, Portable Dishwasher, Built In Dishwasher, Dish Drawer, Compact Dishwasher, Large Dishwasher, Kitchen Appliances
Reference #: DD24DCTW9N
