36" Series 11 Integrated Refrigerator Freezer
SKU: RS3684WRUVE1
Your Price
$9,999.99
None
Selected
Qty: 1
Qty: 1
More options
keyboard_arrow_down
keyboard_arrow_up
Qty: 1
keyboard_arrow_down
Qty: 1
Price with selected options:
Where Can I See This Product in Store?
moreThis product is not on display in our showrooms.
Estimated Delivery Price
Enter your zip code to get a delivery estimate.
Ask a Question
lessDimensions:
35.75" W
×
84.0" D
×
24.0" H
| Width (side to side) | 35.75 |
| Depth (front to back) | 84.0 |
| Height (bottom to top) | 24.0 |
| Refrigerator Capacity Ranges | 14-22 cu.ft. |
Disclaimer
Description
Experience the pinnacle of refrigeration design with our most advanced model. Featuring an elegant interior, this refrigerator embodies premium functionality and style. Designed to optimize energy efficiency, it comes complete with an ice maker and internal water dispenser.
Finish Panel Ready Hinge Right Hinge
Finish Panel Ready Hinge Right Hinge
- 1
- 2
- 3
- Designed to optimize energy performance and efficiency
- With a premium interior for a refined look and feel, this model is the highlight of our Integrated collection
- Enjoy convenient access to fresh, chilled water and ice with the internal water dispenser and ice maker
- For optimal food care, the Variable Temperature Drawer lets you switch between three modes: Chill, Fridge, or Pantry
Rebates
view available rebates
Specifications
Specifications
Product
Icemaker
Yes
Icemaker
- Yes
Sabbath Mode
No
Sabbath Mode
- No
Wifi Enabled
No
Wifi Enabled
- No
Refrigerator Type
Bottom Freezer
Refrigerator Type
- Bottom Freezer
Refrigerator Total Capacity
19.0
Refrigerator Total Capacity
- 19.0
Install Type
Built-In
Install Type
- Built-In
ADA Compliant
No
ADA Compliant
- No
Water Dispenser
Yes
Water Dispenser
- Yes
Energy Star Compliant
No
Energy Star Compliant
- No
Dimensions
Height (bottom to top)
24.0" H
Height (bottom to top)
- 24.0" H
Width (side to side)
35.75" W
Width (side to side)
- 35.75" W
Depth (front to back)
84.0" D
Depth (front to back)
- 84.0" D
Refrigerator Capacity Ranges
14-22 cu.ft.
Refrigerator Capacity Ranges
- 14-22 cu.ft.
Storage
Number of Shelves
3
Number of Shelves
- 3
Style Elements
Color Name
Custom Panel Ready
Color Name
- Custom Panel Ready
Accessories (sold separately)
Door panel stainless steel Left hinge 84"
RD3684WLD
Door panel stainless steel Left hinge 84"
- RD3684WLD
Door panel stainless steel Right hinge 84"
RD3684WRD
Door panel stainless steel Right hinge 84"
- RD3684WRD
Handle kit Classic
AHCLRD3684W
Handle kit Classic
- AHCLRD3684W
Handle kit Contemporary round, aluminium
AHSRD3684W
Handle kit Contemporary round, aluminium
- AHSRD3684W
Handle kit Contemporary square fine, aluminium
AHD5RD3684W
Handle kit Contemporary square fine, aluminium
- AHD5RD3684W
Handle kit Contemporary square fine, black
AHD5RD3684WB
Handle kit Contemporary square fine, black
- AHD5RD3684WB
Handle kit Professional round flush
AHP3RD3684W
Handle kit Professional round flush
- AHP3RD3684W
Handle kit Professional round flush, Brass off-stands
AHP3RD3684WBA
Handle kit Professional round flush, Brass off-stands
- AHP3RD3684WBA
Handle kit Professional round flush, Dark Copper off-stands
AHP3RD3684WDC
Handle kit Professional round flush, Dark Copper off-stands
- AHP3RD3684WDC
Joiner kit
AJ-RS84LR
Joiner kit
- AJ-RS84LR
Capacity
Volume
19.6cu ft
Volume
- 19.6cu ft
Volume freezer
6.7cu ft
Volume freezer
- 6.7cu ft
Volume refrigerator
11.6cu ft
Volume refrigerator
- 11.6cu ft
Volume variable temperature compartment
1.3cu ft
Volume variable temperature compartment
- 1.3cu ft
Consumption
Energy rating
Energy star
Energy rating
- Energy star
Energy usage
381 kWh/yr
Energy usage
- 381 kWh/yr
Features
Fruit and vegetable bins
1
Fruit and vegetable bins
- 1
Full extension drawers
2
Full extension drawers
- 2
Full width door shelves
3
Full width door shelves
- 3
Designed to optimize energy performance and efficiency, With a premium interior for a refined look and feel, this model is the highlight of our Integrated collection, Enjoy convenient access to fresh, chilled water and ice with the internal water dispenser and ice maker, For optimal food care, the Variable Temperature Drawer lets you switch between three modes: Chill, Fridge, or Pantry
- Designed to optimize energy performance and efficiency
- With a premium interior for a refined look and feel, this model is the highlight of our Integrated collection
- Enjoy convenient access to fresh, chilled water and ice with the internal water dispenser and ice maker
- For optimal food care, the Variable Temperature Drawer lets you switch between three modes: Chill, Fridge, or Pantry
Freezer Features
Freezer bins
1
Freezer bins
- 1
Freezer trays
1
Freezer trays
- 1
Full extension clear bins
1
Full extension clear bins
- 1
Installation Dimensions
Minimum inside width of cabinetry frame
36 "
Minimum inside width of cabinetry frame
- 36 "
Minimum internal depth of cabinetry
25 "
Minimum internal depth of cabinetry
- 25 "
Minimum internal height of cabinetry
84 "
Minimum internal height of cabinetry
- 84 "
Performance
Humidity controlled crisper bins
2
Humidity controlled crisper bins
- 2
Variable food modes
Pantry; Fridge; Chill
Variable food modes
- Pantry; Fridge; Chill
Power requirements
Rated current
10A
Rated current
- 10A
Supply frequency
60Hz
Supply frequency
- 60Hz
Supply voltage
115V
Supply voltage
- 115V
Product dimensions
Depth
24 "
Depth
- 24 "
Height
84 "
Height
- 84 "
Width
35 3 / 4 "
Width
- 35 3 / 4 "
Product information
Packaged weight
530lbs
Packaged weight
- 530lbs
Warranty
Parts and labor
2 years
Parts and labor
- 2 years
Sealed system parts and labor
5 years
Sealed system parts and labor
- 5 years
Item & Dimensions
Manufacturer
Fisher and Paykel
Manufacturer
- Fisher and Paykel
The Refrigerators 36" Series 11 Integrated Refrigerator Freezer, made by Fisher and Paykel,
is brought to you by Sherman's. Sherman's is a local furniture store, serving the Peoria, Normal, and Peru, IL area. Product availability may vary.
Contact us for the most current availability on this product.
Collection Details
The Refrigerators collection is an amazing option if you are looking for
Appliances.
Our store serves the Peoria, Normal, and Peru, IL area.
Similar search terms: Refrigerator, Refrigerator with Bottom Freezer, Built-In Refrigerator, Side by Side Refrigerators, Built In Side x Side, Compact Refrigerator, Fridge, Refrigerator without a Freezer, Under the Counter Refrigerator, Fridge, Refridgerators, Appliances, Kitchen Appliances, Icebox, Iceboxes, Residential Refrigerators, Cold Storage
Reference #: RS3684WRUVE1
